KPG200C
KING POWER
8502120000
| Specification | Details |
|---|---|
| Brand Name | King Genset |
| Generator Set Model | HF200GF |
| Generator Power | 200kva |
| Power Factor | COSΦ = 0.8 (lagging) |
| Output Voltage | 110V-480V |
| Generator Set Current | 270A |
| Rated Frequency | 50/60Hz |
| Rated Speed | 1500/1800rpm |
| Fuel Grade | 0 # light diesel (normal temperature) |
| Diesel Generator Size | 18007501300mm |
| Diesel Generator Weight | 860kg |
| Steady State Voltage Adjustment Rate (%) | ≤± 1 |
| Voltage Fluctuation Rate (%) | ≤ ± 0.5 |
| Transient Voltage Adjustment Rate (%) | ＋20 ～－15 |
| Voltage Stabilization Time (s) | ≤1 |
| Steady State Frequency Adjustment Rate (%) | ≤ ± 1 |
| Frequency Fluctuation Rate (%) | ≤ ± 0.5 |
| Transient Frequency Adjustment Rate (%) | + 10 ~ -7 |
| Frequency Stabilization Time (s) | ≤3 |
| Diesel Generator Fuel Consumption | 204g/kW·h at 100% load |
| Diesel Generator Volume (LP7m) | 75dB（A） |
| Diesel Engine Brand | weichai |
| Engine Model | WP6D167E200 |
| Engine Cylinder Number | 6/ L Type |
| Bore Stroke | 105 *130mm |
| Compression Ratio | 18:1 |
| Start Method | DC24V Electric start |
| Cooling Method | Closed water-cooling |
| Oil Supply Method | Direct injection |
| Speed Regulation Method | Mechanical |
| Intake Method | Natural inhalation |
| Overload Capacity | 110% |
| Diesel Engine Speed | 1500rpm |
| Generator Brand | HENGFHA Brushless Generator (Optional: MARATHON, STAMFORD, FARADAY, LEROY-SOMMER) |
| Generator Model | hf-200 |
| Generator Power | 200kva |
| Rated Voltage | 110V-480V |
| Insulation Class | H class |
| Protection Level | IP22 |
| Wiring Mode | Three-phase four-wire, Y-connection |
| Adjustment Method | AVR (Automatic Voltage Regulator) |
| Output Frequency | 50Hz |
| Output Factor | COSΦ = 0.8 (lag) |
| Genset Standard Features | Direct injection internal combustion engine (Diesel), AC synchronous generator (Single Bearing), Water Radiator design for 40-45℃ Ambient belt-driven fans and guards, Generation output air switch, Standard control panel, Steel common base with shock absorber, Dry-type air filter, fuel filter, oil filter, starting motor, Self-charging alternator, Starter battery and connecting cables, Industrial 9dB muffler and accessories, The engine and alternator's original technical papers, manuals and testing reports ship with GenSet |
Versatile Power Range: Available in 100kva to 500kva, King Genset offers reliable backup power for industrial and commercial needs.
Robust Engine Options: Choose from top-tier engines like SDEC, WEICHAI, YUCHAI, RICARDO, PERKKINS, and CUMINS, ensuring optimal performance.
Advanced Engine Specifications: Featuring a 6-cylinder, water-cooling system, turbocharged engine with DC12V electric start for efficient operation.
Smart Control Systems: Equipped with Smartgen HGM6110, DeepSea, or Harsen controllers for precise monitoring and management.
Comprehensive Protection: Includes overload protection, low oil shutdown, and automatic voltage regulation for safety and reliability.
Customizable Options: Tailor your generator with remote control, battery charger, soundproof canopy, or mobile trailer to fit your specific needs.
Silent Operation: Choose silent or super silent types to minimize noise, maintaining a sound level of 75dB(A) at 7 meters.
Global Warranty: Benefit from a 12-month/1000-hour warranty with global service for major components.
King Genset's diesel generator set is designed to ensure uninterrupted operations, offering efficiency and durability for your business.
Expertise in Diesel Generators: King Genset, a renowned brand in the power supply industry, brings over 20 years of expertise in manufacturing top-quality diesel generators.
Global Reach: Serving thousands of satisfied customers across more than 50 countries, King Genset is committed to ensuring 100% customer satisfaction, boasting a 95% repurchase rate.
Wide Power Range: Our diesel generator sets range from 3kva to 5000kva, including the versatile 3 Phase 50Hz/60Hz options in 100kva, 200kva, 300kva, 400kva, and 500kva capacities.
Quality Assurance: Every product undergoes strict inspection, guaranteeing a 100% pass rate. If requirements are not met, we offer a full refund.
Customization and Certifications: With a dedicated R&D line and 28,000 square meters of industrial space, King Genset customizes products to meet specific needs. We hold CE and ISO certifications and provide Certificates of Origin.
Trusted Partnerships: Collaborations with leading brands like CUMMINS, PERKINS, and VOLVO ensure reliability and performance.
Invitation to Inquiry: Discover high-quality diesel generators tailored for industrial and commercial entities. Contact King Genset today.
Versatile Usage: Ideal for industrial and commercial entities, King Genset's 3 Phase Diesel Generators (100kva to 500kva) are perfect for construction sites, manufacturing plants, and large-scale operations.
Reliable Standby Power: Ensure uninterrupted operations during power outages with our generators, designed for efficiency and durability.
Emergency Solutions: Equip your emergency crews with dependable power sources, backed by King Genset's commitment to quality and a 100% pass rate on inspections.
Global Reach: Trusted by thousands of customers in over 50 countries, King Genset delivers robust power solutions worldwide.
Customizable Options: Tailor your generator set with silent or trailer types to meet specific operational needs and enhance operational efficiency.
Customer Assurance: Experience peace of mind with our 100% full refund policy if the product does not meet your requirements.
Invitation to Collaborate: We welcome you to visit us and explore opportunities for a pleasant and productive partnership.
Pros:
Rapid Delivery: King Genset ensures your operations aren't disrupted with our fastest delivery time of just 1 day.
Cost-Effective Pricing: Benefit from factory direct prices and the possibility of a 3% or more discount, optimizing your budget.
Customization Options: Tailor your generator set to your specific needs, whether you require silent or trailer types.
Comprehensive Service: Enjoy door-to-door delivery and 24/7 after-sales support, ensuring uninterrupted power solutions.
Quality Assurance: Each generator undergoes strict inspection, guaranteeing a 100% pass rate with a full refund if not met.
Certified Reliability: Our products come with CE ISO certifications, assuring you of high standards and quality.
Warranty Coverage: A robust warranty of one year or 1000 running hours provides peace of mind.
Cons:
Initial Investment: High-quality, customized solutions may require a significant initial outlay.
King Genset's diesel generators are engineered to meet the rigorous demands of industrial and commercial sectors, ensuring efficiency and durability in every unit.
Q: What after-sales service does King Genset provide for its Diesel Generator Sets?
A: At King Genset, we prioritize your operational efficiency with our comprehensive after-sales service available 24/7. Our diesel generator sets, including the 3 Phase 50Hz/60Hz models ranging from 100kva to 500kva, come with a global warranty service. This ensures you receive support wherever your business operates, from construction sites to manufacturing plants.
Q: What are the warranty terms for King Genset products?
A: We offer a one-year warranty or 1000 running hours, whichever comes first. For special projects, we can extend this period. Our warranty covers genset-body defects, excluding quick-wear parts like water tanks and gaskets. Additionally, components such as start motors and alternators have a 6-month warranty.
Q: How does King Genset ensure reliability in after-sales service?
A: With industry-leading brands like Cummins and Perkins powering our generators, and alternators from Leroysomer and Stamford, you benefit from a global warranty service. This ensures seamless operations and peace of mind, crucial for regions prone to power outages.
