KPG500WP
KING POWER
8502131000
The KPG500WP diesel generator set is a medium-sized power generation unit specifically designed for industrial, commercial, and infrastructure applications. It integrates high efficiency, stability, and environmental friendliness. Equipped with a Weichai WP13D490E310 engine, a Wuxi Stanford S5L1D-C41 generator, and a KING POWER DS9610B intelligent controller, this generator set meets diverse requirements for continuous power supply, emergency backup, and mobile power sources.
Model: Weichai WP13D490E310
Type: Inline six-cylinder, turbocharged intercooled, electronically controlled high-pressure common rail diesel engine
Displacement: 12.54L
Rated Power: 490kW (standby) / 400kW (prime)
Speed: 1500rpm
Fuel Consumption Rate: ≤205g/kW·h (under full load)
Emission Standard: Compliant with China National Phase III emission standards; supports reduced power operation at altitudes ≤4000m.
Technical Highlights:
Electronically controlled fuel injection technology optimizes combustion efficiency and reduces fuel consumption.
Closed-loop water cooling system ensures stable operation in high-temperature environments.
Inline six-cylinder design minimizes vibration and noise, extending mechanical lifespan.
Model: Wuxi Stanford S5L1D-C41
Type: Brushless self-excited AC synchronous generator
Rated Power: 450kVA (standby) / 400kVA (prime)
Output Voltage: 400V/230V (three-phase four-wire system)
Frequency: 50Hz
Insulation Class: Class H (withstanding 180°C)
Protection Class: IP23 (dust and water resistance)
Technical Highlights:
AVR automatic voltage regulator maintains steady voltage fluctuations ≤±1%.
Waveform distortion rate <4%, meeting power supply requirements for precision equipment.
2/3 winding pitch design reduces harmonic interference and improves power quality.
Model: KING POWER DS9610B
Functions:
Automatic Start/Stop: Activates automatically upon mains power failure and shuts down upon restoration.
Remote Monitoring: Supports data transmission via RS485/CAN bus interfaces with MODBUS protocol compatibility.
Fault Diagnosis: Real-time monitoring of oil pressure, water temperature, speed, and other parameters; triggers protective shutdown upon exceeding limits.
Parallel Operation Control: Optional automatic paralleling module for multi-unit parallel operation.
Energy-Saving Mode: Adjusts engine speed automatically based on load demand to reduce fuel consumption.
Operating Interface: 7-inch LCD touchscreen with Chinese/English language options, displaying operational parameters, fault codes, and maintenance reminders.
| Item | Specification |
|---|---|
| Prime Power | 360kW/450kVA |
| Standby Power | 400kW/500kVA |
| Steady-State Voltage Regulation | ≤±1% |
| Transient Voltage Regulation | -15%~+20% (recovery within ≤4 seconds) |
| Steady-State Frequency Regulation | ≤±0.5% |
| Noise Level (7m) | ≤105dB (open-frame) / ≤85dB (soundproof) |
| Dimensions (L×W×H) | 3650×1270×1860mm (open-frame) |
| Weight | Approx. 3200kg |
Prime Power Source: Used as the sole power supply in remote areas without grid access (e.g., mines, oil fields, islands).
Backup Power Source: Ensures emergency power for critical facilities such as data centers, hospitals, and communication base stations.
Mobile Power Source: Trailer-mounted units enable rapid deployment to construction sites, large-scale events, and disaster relief areas.
Distributed Energy: Complements renewable energy sources like solar and wind to form microgrid systems.
Warranty Period: 1 year or 1000 operating hours (whichever comes first).
Service Network: Over 300 service centers nationwide with 24-hour emergency response.
Parts Supply: Sufficient inventory of genuine parts with 48-hour delivery.
Training Support: Free operator training and maintenance guidance.
Load Type: Reserve 20%-30% power margin for loads involving high-power motor starting.
Environmental Adaptability: Derate power for high-altitude applications; select anti-condensation heaters for high-humidity environments.
Noise Reduction: Choose soundproof models (≤75dB@1m) for residential or indoor use.
Extended Functions: Select ATS automatic transfer switches and paralleling modules for parallel operation or grid connection requirements.
The KPG500WP diesel generator set delivers exceptional performance, reliability, and intelligent control, providing comprehensive power solutions for ensuring production continuity and emergency safety. It is an ideal choice for safeguarding critical operations.
